Hobby Master – Lockheed S-3B Viking ,“President George Bush“ Navy 1 VS-35, USS Abraham Lincoln, 1st May 2003

Popis

-sběratelský model letadla  S-3A Viking  1/72
-provedení: kovový model s plastovými částmi
-model je v kvalitním provedení
-součástí balení je stojánek

                         Lockheed S-3 Viking

Lockheed S-3 Viking je čtyřmístné proudové letadlo, které bylo používáno námořnictvem USA (United States Navydále jen US Navy) k identifikování, sledování a ničení nepřátelských ponorek. Od konce 90. let 20. století byly úkoly letounu S-3B zaměřeny na boj s povrchovými cíli a tankování ve vzduchu. Letouny Viking byly rovněž používány pro elektronický boj a jako hlídková letadla v rámci bojové skupiny letadlové lodi.

The Lockheed S-3 Viking is a four-seat, twin-engine turbofan-powered jet aircraft that was used by the U.S. Navy primarily for anti-submarine warfare. In the late 1990s, the S-3B’s mission focus shifted to surface warfare and aerial refueling.

General characteristics

• Crew: 4 (Pilot, Co-Pilot/COTAC, TACCO, Sensor Operator/TFO)
• Length: 53 ft 4 in (16.26 m)
• Wingspan:
  • Unfolded: 68 ft 8 in (20.93 m)
  • Folded: 29 ft 6 in (9.00 m)
• Height: 22 ft 9 in (6.93 m)
• Wing area: 598 ft² (55.56 m²)
• Aspect ratio: 7.73
• Empty weight: 26,581 lb (12,057 kg)
• Loaded weight: 38,192 lb (17,324 kg)
• Max. takeoff weight: 52,539 lb (23,831 kg)
• Internal fuel capacity: 1,933 US gal (13,145 lb)(7,320 L) of JP-5 fuel
• External fuel capacity: 2 × 300 US gal (4,080 lb)(1,136 L) tanks
• Powerplant: 2 × General Electric TF34-GE-2 turbofans, 9,275 lb_f (41.26 kN) each

Performance

• Maximum speed:
  • 429 kn (493 mph, 795 km/h) at sea level
  • Mach 0.79, 450 kn (514 mph, 828 km/h) at 20,000 ft (6,100 m)
• Cruise speed: 350 kn (405 mph, 650 km/h)
• Stall speed: 97 kn (112 mph, 180 km/h)
• Range: 2,765 nm (3,182 mi, 5,121 km
• Combat Radius: 853 km  (530 mi))
• Ferry range: 3,368 nm (3,875 mi, 6,237 km)
• Service ceiling: 40,900 ft (12,465 m)
• Rate of climb: 5,120 ft/min (26.0 m/s)
• Wing loading: 68.5 lb/ft² (334 kg/m²)
• Thrust/weight: 0.353

Armament

• Up to 4,900 lb (2,220 kg) on four internal and two external hardpoints, including:
  • 10 × 500 lb (227 kg) Mark 82 bombs
  • 2 × 1000 lb (454 kg) Mark 83 bombs
  • 2 × 2000 lb (908 kg) Mark 84 bombs
  • 6 × CBU-100 cluster bombs
  • 2 × Mark 50 torpedoes
  • 4 × Mark 46 torpedoes
  • 6 × mines or depth charges
  • 2 × B57 nuclear bombs
  • 2 × AGM-65E/F Maverick missiles
  • 2 × AGM-84D Harpoon missiles
  • 1 × AGM-84H/K SLAM-ER missile
• The two underwing hardpoints can also be fitted with unguided rocket pods or 300 US gal (1,136 l) fuel tanks.

Avionics

• AN/APS-116 sea search radar, maximum range 150 nmi (173 mi, 278 km)
  • Upgraded on S-3B to AN/APS-137 Inverse Synthetic Aperture Radar (ISAR)
• OR-89 forward looking infrared (FLIR) camera with 3× zoom
• AN/ARS-2 sonobuoy receiver with 13 blade antennas on the airframe for precise buoy location (Sonobuoy Reference System)
• AN/ASQ-81 magnetic anomaly detector (MAD)
• AN/ALR-47 Electronic Support Measures (ESM) emitter-location system, with boxy receiver pods fitted to the wingtips, to locate adversary communications and radar transmitters
• AN/ASN-92 Inertial navigation system (INS) with doppler radar navigation and TACAN
• Up to 60 sonobuoys (59 tactical, 1 Search and Rescue)
